Description
A Zener diode works like a normal diode in the FORWARD direction, but when voltage is applied in the REVERSE direction it does something really useful. At a specified reverse voltage, it starts to conduct. In other words, if you apply, say 12V (for a 12V Zener) across the diode it will start to conduct current. When the Zener starts to draw current this has the effect of regulating the positive (+) voltage. Jaycar carries a range of Zener diodes from 3.3V to 75V.
Features:
| VOLTS | TYPE | WATTS |
|
12V |
1N5349B |
B |
Specifications:
| Power Dissipation | 1W |
| Derate above 50C | 6.67mW/C |
| Storage Temperature Range | -65C-200C |
| Operating Junction Temperate | 200C |
| Thermal resistance junction to lead | 53.5C/W |
| Thermal resistance junction to ambient | 100C/W |
| Lead temperature (1/16″ from case for 10 seconds) | 230C |
| Surge power | 10W |
Downloads
- Download Datasheet
