Description
All feature rugged construction and quick connect terminals for easy installation.
DPDT PANEL MOUNT RELAYS
Two models available. One with a nominal 240VAC coil and one with 24VDC coil.
Contact Form: DPDT
Contact Rating: 30A
24V Model Coil Resistance: 350 Ohm
240V Model Coil Resistance: 3800 ohm @ 50Hz
Specifications:
| DC Contact Voltage | 24V |
| Coil Resistance | 350 |
| Input | DC or AC Dual Mode |
| Contact format | DPDT |
| AC Contact Voltage | 250V |
| DC Switching Current (Opening) | 30A |
| DC Voltage | 24V |
| AC Voltage | 250V |
| DC Current Draw | 30A |
| Mounting Method | Panel,Chassis |
Downloads
- Download Datasheet
