Description
IP67 rated for industrial use or other harsh environments. Dual colour red/green illuminated, metal body, DPDT, push-on/push-off action. Rated for 250VAC @ 3A, with 12VDC LED illumination. Mounting hole 16mm.
Specifications:
| Switch Type | Pushbutton |
| Pole Throw Type | DPDT |
| Switch Function | Single Action Momentary |
| Poles / Contacts | 2 pole |
| Throws / Positions | 2pos |
| Switch Connection | Solder Legs |
| Attachment / Securing Method | Collar / Nut |
| Round Mount Hole Diameter | 16mm |
| Mounting Method | Panel |
| AC Voltage rating | 250V |
| AC current rating | 3A |
