Description
POWERSHIELD Defender Rackmount 800VA (480W) Line Interactive UPS, 6x NZ Power Sockets with Surge+Battery Backup. Compatible with ALL Wall Mounted Racks.
PowerShield has taken the smarts from our most popular range of UPSs and built them into a rack mount UPS -perfect for shallow, wall mounted Comms cabinets.
Features:
- Compact Footprint
- User-Replaceable Batteries
- Silent Operation – No Fans
- Compatible with all wall-mounted racks
- Extra IEC and Australian Outlets
- All Metal Enclosure
- 2RU Size
Specifications:
| Capacity | 800VA / 480W |
| Topology | Line Interactive |
| INPUT | |
| Voltage | 240Vac(Nominal) |
| Voltage Range | 177-290Vac |
| Frequency Range | 50/60Hz (auto sensing) |
| OUTPUT | |
| Output Voltage | 240Vac 10% |
| Frequency Range (Batt. Mode) | 50Hz/60Hz 1Hz |
| Transfer Time | 6ms (Typical) |
| Waveform (Batt. Mode) | Simulated Sine Wave |
| Australian Outlets – UPS & Surge Protection | 2x 10A IEC Sockets, 6 x Australian Sockets |
| BATTERY | |
| Battery Type & Number | 12V / 9AH (x1) |
| Typical Recharge Time | 4~6 hours recover to 90% capacity |
| Backup Time (50% Load) | 8 min |
| PROTECTION | |
| Full Protection | Overload, discharge and overcharge protection |
| Surge Protection | 312Joules / 6500Amps |
| COMMUNICATIONS & MANAGEMENT | |
| Interface | USB interface |
| Software | NetGuard supports – Windows, Linux, Unix and Mac (Free Download) |
| LCD Alarm | AC Mode, Battery Mode, Low Battery (Batt. Mode), Fault, Overload |
| Audible Alarm | Battery Mode, Low Battery (Batt. Mode), Fault, Overload |
| PHYSICAL | |
| Dimension L x W x H | 230 x 438 x 86mm (2RU) |
| Net Weight | 7.7kg |
| OPERATING ENVIRONMENT | |
| Temperature | 0C~40C |
| Humidity | 0%-90% RH (non-condensing) |
| Noise Level | Less than 5dBA @ 1meter (no fan) |
| COMPLIANCE | |
| Safety/EMC | EN62040-1 -1 2003, IEC60950-1 : 2001, EN62040-2 2006 |
| RoHS | Directive 2011/65/EU |
