Description
Red 5x2mm LED 5mcd Rectangular Diffused
Specifications:
| LED Type | Rectangular LED |
| Illumination Type | Single Colour |
| Light Colour | Red |
| Light Wavelength | 643nm |
| Lens Type | Diffused |
| Viewing Angle | 155 |
| Intensity | 5mcd |
| Vf (typ) – Typical Forward Voltage | 2.3V |
| If (typ) – Typical Forward Current | 20mA |
| If (max) – Maximum Forward Current | 20mA |
| Resistor for 5VDC | 130 |
| Resistor for 9VDC | 330 |
| Resistor for 12VDC | 470 |
Downloads
- Download Datasheet
