Description
This panel mount solid state relay offers 4-32VDC input control, with a switched output rated at 240VAC/ 40Amps. Note, please refer to the data sheet Precautions 1, 2 and 3, and make sure the heat sink size is suitable for high current loads. The solid state relay has a dielectric strength of 4000VAC 50/60Hz.
Features
4000V dielectric strength
Built-In snubber
TRIAC AC output
Panel Mount
DC input control
RoHS compliant
Note: Suitable for switching AC only
Specifications:
| Release Time |
0.5ms |
| Dropout Voltage |
1V |
| Device Type |
Solid State Relay |
| Input |
DC |
| Contact format |
SPST |
| AC Contact Voltage |
48V-280V |
| AC Switching Current (Opening) |
40A |
| Operation Time |
0.5ms |
| Item connection |
Screw Terminals |
| DC Voltage |
4V |
| DC Current Draw |
28A |
| Attachment / Securing Method |
Screw Down |
| Mount Screw Size |
2mm-4.5mm |
| Overall Screw Spacing (H) |
47.5mm |
| Mounting Method |
Chassis |
| Mount Screw Quantity |
2pc |
